#1011156671 | Mfg #MED3-A1 | Clinical Laboratory

Med-Scope™ Med3-A1 Advanced Compound Microscope Trinocular Head Infinity Corrected Plan 4X / 10X / 40X / 100X External DC Auto Switching Power Supply / 110 to 240V Coaxial X / Y Mechanical Stage with Adjustable Tension

MICROSCOPE, ADVANCED TRINOC PLAN INFINITY BF 4/10/40/100 D/S
Med-Scope™ Med3-A1 Advanced Compound Microscope Trinocular Head Infinity Corrected Plan 4X / 10X / 40X / 100X External DC Auto Switching Power Supply / 110 to 240V Coaxial X / Y Mechanical Stage with Adjustable Tension

18 mm Field of View

Product Specifications

MSFH #
1011156671
Manufacturer #
MED3-A1
Brand
Med-Scope™ Med3-A1
Manufacturer
Laxco Inc
Country of Origin
China
Application
Advanced Compound Microscope
Condenser
N.A. 1.25 Abbe Condenser with Iris Diaphragm
Head Type
Trinocular Head
Light Source
3W Adjustable
Light Type
LED
Objectives
Infinity Corrected Plan 4X / 10X / 40X / 100X
Power Source
External DC Auto Switching Power Supply / 110 to 240V
Stage Type
Coaxial X / Y Mechanical Stage with Adjustable Tension
UNSPSC Code
41111759

Description

Full Koehler Illumination

10X Eyepieces Corrected for Eyeglasses

Customizable to meet the customer needs; direct Support From Laxco

Carrying Handle

Lightweight, stable main body for easy portability

Rack and pinion focusing mechanism for smooth focusing control

45° observation angle with interpupillary and diopter adjustments

Optional 20X Phase Objective Available

4 position objective nosepiece
