Immunodiagnostic System VITROS® 3600

Calibration: 25 lots per assay may be calibrated with automatic lot; switching; stable for up to 28 days; random-access calibration; bar-coded calibrators

Sample containers: Universal sample trays accommodate: 5 mL, 7 mL, 10 mL collection tubes, 1.5 mL micro-collection containers, VITROS® microsample cups and 0.5 mL and 2 mL cups

Dilution capabilities: Auto reflex dilution; operator requested dilution; off-board dilution calculation

Operator interface: Color-coded graphical user interface; ergonomic flat, low-glare, LCD, 17 Inch touchscreen monitor; numeric keypad on monitor; detached keyboard for maximum flexibility; onboard documentation and animated help (V-Docs); onboard maintenance documentation

Data storage: Read/write disk drive for data input and archiving; USB flash drive (memory stick) capabilities; 5000 sample programs; 25000 samples with ability to archive and retrieve through CD-ROM or memory stick

15 to 30°C/59 to 86°F Operating temperature, 15% to 75% RH ambient relative humidity, up to 2438 Meter/8000 Foot altitude
