Console Freeze Dryer FreeZone

FreeZone 18 Liter Console Freeze Dryers with Stoppering Tray Dryers are designed for lyophilizing moderate to large loads and stoppering vials or serum bottles under vacuum

The console's upright stainless steel collector coil is capable of holding 18 liters of ice before defrosting

A single 1-1/2 hp HCFC/CFC-free refrigeration system cools the collector to -50° C (-58° F), suitable for aqueous samples

The Stoppering Tray Dryer features three 16-1/2 X 12 Inch processing shelves

A single 1 hp HCFC/CFC-free refrigeration system and 1000-watt electric heater cool and heat the fluid medium circulating through channels in the shelves

5 Inch full color capacitive touch screen

Clear acrylic chamber lid, 3/4 Inch thick, with neoprene gasket

Brushed stainless steel and glacier white, powder-coated steel exterior with blue accents

Real time display of collector temperature, vacuum level, and optional End-Zone™ end point detection system

Operating mode (standby or run)

Vacuum set point, alerts, diagnostic tests, user manual, defrost control, and optional drying accessory parameters

Data logging stores and displays data in table or chart format, and may be exported via USB or Ethernet

Hot gas defrost with auto shut off at +60° C (+140° F)

Side-mounted USB port and rear-mounted Ethernet connection
